PoE Power Injector
• PoE InjectorColorBlackSpecificationsStandard: IEEE 802.3/3u/3ab, IEEE 802.3af Power over Ethernet
• 1 x 10/100/1000Mbps DATA-IN (Data only)
• 1 x Power-in
• 1 x 10/100/1000Mbps PWR+DATA OUT (Data + Power)
• Up to 100 Meters
• Recommend Cat 5e/Cat 6 for all runs (not included)
• Data Lines:
Pair 1: Pin 1, 2
Pair 2: Pin 3, 6
• Power:
Input: 100~240V, 50~60Hz, 0.4A max.
Output: 48V DC, 0.4A 18W max.
• Power Consumption: 15.4 Watts (max.)
• Dimensions (W x D x H): 70 x 45 x 25mm (2.75 x 1.8 x 1 in.)
• Weight: 45 g (1.6 oz.)
Note: Requires a PoE splitter or PoE enabled device at the receiving end.
